Tamiya 1/35 SdKfz 184 Elefant

sdkfz184lf

The Elefant.

sdkfz184zim1

Zimmerit. I was supplied with Tamiya’s self adhesive zimmerit but was not happy with the result it gave so I replaced it with my own, using white superfine Milliput and a small screwdriver. This was a very time-consuming job but was worth the extra effort. In this shot you can also see weld beads that were added using stretched sprue softened with liquid cement and textured with the point of a scalpel blade.

sdkfz184zimrear

This shot shows some of the extra detail added. This includes brass and copper wire replacement hatch handles, hinge bolts cut from plastic rod, hooks for hanging the tow cables made from P\E scrap and a bracket to hang the sledge hammer  from plastic card.

sdkfz184dkyel

With construction complete the model received a coat of dark yellow and the tracks were painted a mixture of Tamiya red brown with a touch of flat black.The contact points of the tracks were coloured with a Prismacolor silver pencil.

sdkfz184rl

The camouflage colours were sprayed quite subtly as per my reference and a bucket from the spares box was appropriately beaten up and hung from the jack bracket. The kit’s string tow cable was replaced with copper twine.

sdkfz184is

A couple of spare track links were hung from the tow cable hooks on this side.

sdkfz184rr

The tracks, road-wheels and generally all lower areas were liberally coated with a mix of pastel chalk dust and turpentine.

sdkfz184rf

All the raised detail received a very carefully applied wash of oil based black/brown. This included a heavier but no less careful application to the detail on all the running gear.

sdkfz184cufl

The spare track links (front and rear) received a very heavy dusting of pastel chalk powder.

sdkfz184cufr

Lots of scratches were added with the aid of a very fine brush and a very sharp 6B pencil.

sdkfz184det

More wear and scratches.

sdkfz184finfrnt

Finished! Or so I thought.

sdkfz184fin-rear

At this point I realised that I had forgotten to apply the tactical number decal to the rear end.

sdkfz184lr

Finished!

Billiken’s Cyclops from ‘The 7th Voyage of Sinbad’

cyc_opencrop-2_ps

This is the story of how I rejuvenated my 1984 model of one of my favourite Ray Harryhausen monsters.

cyc_orig cyc_newpaint

1984

2013


 The restoration process

cyc_orig

This is my original paint job, which I was pretty proud of back in 1984. The head, jaw, arms and legs were posable which meant the join lines were very visible. This feature was always unpleasing to my eye.

cyc_strip

The original acrylic paint was removed by spraying the entire model with Isopropyl alcohol and scrubbing with an old toothbrush. This process took quite few hours more than I anticipated and resulted in exposing many, tiny air bubble holes, particularly on his arms, which would have to be filled.

cyc_leghair3

Before any filling of the joints was started I decided to put some hair on his legs. This was done by scratching each individual hair into the vinyl, using a panel scribing tool. After many hours a very pleasing result was achieved, but I don’t think I’ll be doing it again in any hurry!

cyc_nails

Some manicuring was necessary to make his fingernails more representative of the movie original. This was done using a motor tool set to a fairly slow speed and fitted with a very fine, round dental burr (thanks Alice).

cyc_putty4

In this and the next two shots his head, jaw, arms and legs have all been glued in position and filled with Milliput epoxy putty. Note also the new Milliput horn tip and dental work.

cyc_putty3

Some extra warts were added to his back using small drops of CA glue.

cyc_putty2

The filled joints around his neck and jaw were given a coat of liquid filler to make sure that there were no gaps left. You can also see in this shot the tiny holes on his arms have been filled using Milliput.

cyc_newpaint

After studying the movie for hours the new paint job was applied and he is finished.

cyc_rtfrnt

He now stands proudly in the bookshelves right next to my ‘Clash of the Titans’ gorgon, Medusa.

cyc_lft

cyc_lftfrt

Fairy Bower

fairybower49

Fairy Bower, Manly 1949. Painting by my Dad, Stewart G. Wauchop.

fairybower2012

Fairy Bower, Manly 2012. Photograph by me, Christopher G. Wauchop. Little has changed.

More from The Vault. Photos by Brett Green

fw200stb

Revell 1/72 Focke Wulf FW 200 Condor w/Hs 293 Glide bombs

fw200fnt-prt

The Eduard exterior P/E detail set 72 463 was used on this model. This made a big difference, especially the radar antenna!

beaufighter-rear-prt_15

Hasegawa 1/72 Bristol Beaufighter Mk.X of 455 Squadron R.A.A.F. while based in Scotland.

beafighter-prtfnt-mk2

These aircraft were mainly employed in the anti-shipping role.

do335-prtrear

Tamiya 1/48 Dornier Do 335

do335-stdrear

A beautiful kit with very little extra detail added.

Tamiya 1/35 Hetzer. Photos by Brett Green

Tamiya 1/35 Hetzer

Tamiya 1/35 Hetzer. This is a vehicle from 1./Gebirgs-Panzerjager-Abteilung 95, 3 Geberirgsdivision, Tatra Mountains, Czechoslovakia, Jan ’45.

Tamiya 1/35 Hetzer

This was my first attempt at the hairspray  method of weathering. I wasn’t 100% sure what I was doing but the result was OK.

Tamiya 1/35 Hetzer

Tamiya 1/35 Hetzer

The VOYAGERMODEL P/E detail set was used on this model.

hetzer-lfttop-2

The detail on the kit’s MG 34 is beautiful.

hetzer-reardtl-2

The kit’s plastic grab-handles were replaced with brass wire bent to shape.

Tamiya 1/32 Spitfire Mk IX. Photos by Brett Green and me.

mk9_prtf

Tamiya 1/32 Spitfire Mk IX of 453 Squadron RAAF at Hornchurch April 1943.

mk9_high

This aircraft started life as a Mk V and was converted to Mk IX standard by Rolls Royce. It was flown by Wing Commander John Ratten in June 1943.

mk9_prtr

Wing Commander Ratten was credited with 2 kills, 2 shared, 1 probable and 2 damaged before being killed in action in Feb ’45.

mk9_engpt

Finished Rolls Royce Merlin engine fitted to the main airframe.

Tamiya 1/32 Spitfire Mk9

Just waiting for prop and cowling panels to be fitted.

Tamiya 1/32 Spitfire Mk8. Photos by Brett Green.

mk8_high

Mk8 Spitfire of 457 Squadron RAAF built by Brett Green and painted, weathered and detailed by me.

mk8_str

mk8_ptr

mk8_stbf
